Lugar de origen: | Shenzhen China |
---|---|
Nombre de la marca: | OPTFOCUS |
Certificación: | CE,ROHS |
Número de modelo: | OFSX511F |
Cantidad de orden mínima: | 1 PCS |
Precio: | $7-10/UNIT EXW CHINA |
Detalles de empaquetado: | Embalaje 1PCS/BOX 0.2KG/el 19*11*4cm 15.4KG/80PCS/CNT/los 48*43*37.5cm de Netural |
Tiempo de entrega: | 5-8 días laborables |
Condiciones de pago: | T/T, Western Union, PayPal, garantía del comercio del alibaba, Western Union |
Capacidad de la fuente: | 100000 PC/mes |
interfaz del Para arriba-vínculo: | 1 interfaz de XPON, tarifa y TX 1,244 Gbits/s (GPON), tarifa de RX 1,244 Gbits/s y tipo de la fibra | Poder óptico: | dBm 0~4 |
---|---|---|---|
Sensibilidad: | -28 dBm | Conector de la fibra: | Conector de SC/UPC (SC/APC opcional) |
Interfaz de los datos del enlace descendente: | interfaz de Ethernet de la auto-negociación del 1*10/100/1000M, interfaz RJ45 | Indicador LED: | 4 PCS |
Interfaz de fuente de DC: | input+12V 0.5A | Poder: | ≤5W |
Temperatura de funcionamiento: | -5~+55℃ | Peso: | 0.24Kg (unidad central) |
Palabras claves: | onu del gepon |
Contact:
Specification:
Tech parameters | description |
Up-link interface |
1 XPON interface,SC single mode single fiber RX 2.488 Gbits/s rate and TX 1.244 Gbits/s(GPON), RX 1.244 Gbits/s rate and TX 1.244 Gbits/s(EPON) rate Fiber type:SC/UPC Optical power:0~4 dBm Sensitivity:-28 dBm safety: ONU authentication mechanism |
Wavelength(nm) | TX 1310nm,RX 1490nm |
Fiber connector | SC/UPC connector (SC / APC optional) |
Down-link data interface | 1*10/100/1000M auto-negotiation Ethernet interface, RJ45 interface |
Indicator LED | 4 pcs |
DC supply interface | input+12V 0.5A |
Power | ≤5W |
Operating temperature | -5~+55℃ |
Humidity | 10~85%(non-condensation) |
Storage temperature | -30~+70℃ |
Dimension(MM) | 85*85*28mm(mainframe) |
Weight | 0.24Kg(mainframe) |
